RGS-325 Piston Rod Guided Spanner Wrench

DOWNLOAD CATALOGUE

RGS-325 Piston Rod Guided Spanner Wrench

The RGS-325 attaches to piston rods from 1.00″ to 3.25″ in diameter. The piston rod is protected by built-in nylon pads. A simple adjustment centers the wrench on the head. The appropriate slot or pin dies engage the head and follow it out as it is unscrewed.

  • Fits Rods 25.4–82.55 mm
  • Won’t Slip or Damage Rod
  • Built-In Nylon Pad Protection
  • Heat-Treated to RC 52

Why Industry Leaders Choose the RGS-325

  • Won’t Slip
  • Saves Time
  • Eliminates destructive removal techniques
  • Eliminates dangers of using old methods of the mechanics
  • Eliminates damage to the spanner holes and slots

When corrosion, cylinder distortion, or thread compounds make threaded cylinder head removal a time consuming job, technicians resort to cutting away the barrel, cutting the gland, torch heating or using a hammer and punch.

Now there is a spanner wrench usable in shop or field that makes high torque threaded gland head removal quick, easy and much safer because it won’t slip and it won’t damage the rod, head or its spanner slots or holes.

If you are tired of time consuming struggles with threaded cylinder head glands, the unique, new RGS-325 will make life a lot easier. And if you are tired of broken spanners, slipping chain wrenches and damaged threaded glands, the tool room quality RGS-325 will end the problems for good. It is heat treated to RC 52 for maximum strength.

For complete specification please contact [email protected]

GET QUOTE

Technical Data

Specifications

Technical Specs

Specification Table
Model RGS-325
Max. Capacity Rod Diameter 3.25 in. (82.55 mm)
Max. Capacity Cylinder Barrel Diameter 9.0 in. (228.6 mm)
Min. Capacity Rod Diameter 1.0 in. (25.4 mm)
Spanner Pins/Slots Will accommodate in both front and side of gland
Spanner Hole Configurations Slots or holes in either 90° or 120° configurations
Spanner Pin Material (All) 4140 (RC 52)
Spanner Sizes (Pins) .1875 in. (4.76 mm) / .250 in. (6.35 mm) / .3125 in. (7.94 mm) / .375 in. (9.53 mm) / .4375 in. (11.11 mm)
Spanner Sizes (Slots) .250 in. (6.35 mm) / .375 in. (9.53 mm) / .500 in. (12.7 mm)
