Technical Specs
| Standard Die Sets | ||
|---|---|---|
| Code | Swage Range | Length(mm) |
| HCA-32-16 | 16 – 19 | 55 |
| HCA-32-19 | 19 – 23 | 55 |
| HCA-32-23 | 23 – 26 | 55 |
| HCA-32-29 | 29 – 34 | 88 |
| HCA-32-39 | 39 – 45 | 88 |
| HCA-32-45 | 45 – 51 | 88 |
| HCA-32-51 | 51 – 57 | 88 |
| HCA-32-57 | 57 – 63 | 88 |
| HCA-32-68 | 68 – 74 | 88 |
| Extra Die Sets | ||
| HCA-32-14 | 14 – 16 | 55 |
| HCA-32-26 | 26 – 30 | 55 |
| HCA-32-34 | 34 – 39 | 88 |
| HCA-32-63 | 63 – 68 | 88 |
| HCA-32-74 | 74 – 77 | 88 |
| HCA-32-77 | 77 – 83 | 88 |
| Specification | ||
|---|---|---|
| Capacity | -32 (DN50) | |
| Actuator | Single acting spring return 65 tonne ram | |
| Setting | Direct reading micrometer type gauge | |
| Std Dies | 16, 19, 23, 29, 39, 45, 51, 57, 68mm | |
| Extra Dies | 14, 26, 34, 63, 74, 77mm | |
| Flared one piece dies and special form are available | ||
| General | Max dies length Max swage dia Max die opening Die holder opening |
= 88mm = 71mm = die + 28mm = 122mm |
