Technical Specs
| Model Number | Capacity (ton) | Stroke (mm) | Working Pressure (kg/cm2) | Approx Weight (kg) | Operation | Universal Tooling Set (Included in the package) | Pin Details | |||
|---|---|---|---|---|---|---|---|---|---|---|
| Min Dia. (mm) | Max Dia. (mm) | Min Length (mm) | Max Length (mm) | |||||||
| HEPP-200 M | 200 | 350 | 650 | 630 | Hand pump | 15 Sets to cover 19.3mm up to 76.2mm in diameter | 19.3 | 76.2 | 311 | 415 |
| HEPP-200 E | 200 | 3500 | 650 | 630 | Electric pump (dual control pump 2 in 1) | 15 Sets to cover 19.3mm up to 76.2mm in diameter | 19.3 | 76.2 | 311 | 415 |
| HEPP-230 M | 230 | 350 | 650 | 680 | Hand pump | 7 Sets to cover up to 85mm in diameter | 22 | 85 | 311 | 415 |
| HEPP-230 E | 230 | 350 | 650 | 680 | Electric pump (dual control pump 2 in 1) | 7 Sets to cover up to 85mm in diameter | 22 | 85 | 311 | 415 |
| HEPP-300 M | 300 | 600 | 700 | 1420 | Hand pump | 15 Sets to cover up to 85mm in diameter | 22 | 85 | 290 | 500 |
| HEPP-300 E | 300 | 600 | 700 | 1420 | Electric pump (dual control pump 2 in 1) | 16 Sets to cover up to 85mm in diameter | 22 | 85 | 290 | 500 |
