HCS-2520 Hydraulic Cylinder Servicer

HCS-2520

HCS-2520 Hydraulic Cylinder Servicer

The HCS-2520 utilizes compressed air to provide hydraulic power and thus requires no electricity to operate. This model is an excellent, low-cost hydraulic cylinder servicer that would prove to be a productive addition to any hydraulic repair facility. The HCS-2520 will produce up to 25,000 lb-ft (3450 kg-m) of torque to remove threaded glands and piston retaining nuts, powered solely by an air/hydraulic system. It is designed to service cylinders up to 26 feet (7.9 m) in extended length, with diameters up to 22 inches (558.8 mm).
The machine utilizes spring return, single acting hydraulic rams to provide high torque and high rod extraction force. It will service a wide range of cylinder sizes where maximum speed is not a primary concern. This model has proven to be extremely successful in countless installations throughout the world, particularly where 3 phase power is not an option, as well as where volatile atmospheres exist.

The HCS-2520 also can be easily mounted on mobile hydraulic repair vehicles, to break down cumbersome cylinders that need to be repaired in the field. This feature alone has made the HCS-2520 ideal for hydraulic repair markets in areas such as the Middle East and Russia/Siberia.

The HCS-2520 is available certified CE.

For complete specification please contact sales@hemsltd.com

Technical Specs

Tuxco Model Torque Capacity Single / Double Acting Torquer Max Capacity Cylinder Length Max Capacity Cylinder Diameter Max. Req. Floor Space Power Required Horse Power Nut Runner Torque Nut Runner Speed Wrench Built-In Spanner Access Required Torquer Stroke Speed Rod Extraction Installation Speed Pendent Control Extraction Force
lb. ft. (kg-m) (m) (mm) (kN)
HCS-2520 25,000
(3457.7)		 SINGLE 26 ft.
(7.9)		 22 in.
(558.8)		 30′ x 3′ with 10′ of air space on one end SHOP AIR N/A N/A N/A YES FRONT
REAR		 10″ STROKE
29 Sec./Ft.		 14″ STROKE
33 Sec./Ft.		 NO 9,000 lbs.
(44.1)
