Technical Specs
| Model Number | Capacity (ton) | Stroke (mm) | Working Pressure (kg/cm2) | Approx Weight (kg) | Operation | Universal Tooling Set (Included in the package) | Pin Details | |||
|---|---|---|---|---|---|---|---|---|---|---|
| Min Dia. (mm) | Max Dia. (mm) | Min Length (mm) | Max Length (mm) | |||||||
| HEPP 65T/E | 65 | 60 | 700 | 130 | Dual Control (2-in-1) | 6 Sets to cover 30.1mm up to 52.3mm in diameter | 30.1 | 52.3 | – | – |
| HEPP 65T/M | 65 | 60 | 700 | 130 | Manual | 6 Sets to cover 30.1mm up to 52.3mm in diameter | 30.1 | 52.3 | – | – |
| HEPP-100 M | 100 | 350 | 650 | 205 | Hand pump | 10 Sets to cover 19.3mm up to 60.2mm in diameter | 19.3 | 60.2 | 160 | 320 |
| HEPP-100 E | 100 | 350 | 650 | 205 | Electric pump (dual control pump 2 in 1) | 10 Sets to cover 19.3mm up to 60.2mm in diameter | 19.3 | 60.2 | 160 | 320 |
| HEPP-150 M | 150 | 350 | 650 | 480 | Hand pump | 12 Sets to cover 23.7mm up to 70mm in diameter | 23.7 | 70 | 311 | 365 |
| HEPP-150 E | 150 | 350 | 650 | 480 | Electric pump (dual control pump 2 in 1) | 12 Sets to cover 23.7mm up to 70mm in diameter | 23.7 | 70 | 311 | 365 |
Videos
Request A Callback
Get in Touch
If you have an enquiry about any of our products, please get in touch and we will get back to you as soon as possible. Alternatively, contact us on our live chat.
You can also visit our dealers page where you can search for a dealer in your area.
Request a callback
Product Reviews
This is a quality tool, saves us so much time rather than wait for a third party to arrive. It has probably paid for itself many times. I would definitely recommend this press if you want to save downtime.
Wonderful interaction and communication with Roy Hatcher very professional coupled with the necessary technical expertise.
Goods were dispatched as promised and on arrival was inspected at our client’s premises.
The packaging and quality of the product was found to be of excellent quality.
Together with our client, the total experience from beginning to end, was exemplary.
Thank you, it was a pleasure in dealing with you.
Vincent Govender – Shosholoza Technologies South Africa
Amazing service from HEMS and excellent communication. Once arrived on site the build quality was inspected and passed with flying colors
Delivered within a few days of order, unboxed on job site and put straight to work. Having a manual hand pump included as well as an electric power pack helps from job to job. Impressed with adaptor set supplied which ensured a safe press.
