Track Press
HEMS Track Press

Track Press

The stationary track press has been rigorously tested for performance and reliability in our production facilities, ensuring it can withstand high volumes and continuous workloads with ease.

With the launch of its new stationary track press, HEMS expands its reputable line of machinery and equipment for tracked vehicle maintenance. The three HEMS models facilitate safe and efficient assembly and disassembly of chains with pitches up to 325mm.

For complete specification please contact [email protected]

Technical Specs

Stationary Track Press
Description HEM-UC/200T HEM-UC/300T HEM-UC/400T HEM-UC/500T
Capacity of Cylinders 100 Ton 150 Ton 200 Ton 250 Ton
Bore 180mm 220mm 260mm 290mm
RAM 140mm 180mm 220mm 240mm
Press Daylight 800mm 900mm
Max Track Pitch 270mm 280mm 300mm 325mm
Effective Area 254.46 cm/sq 380.13 cm/sq 530.93 cm/sq 660.52 cm/sq
Working Pressure 400 bar 400 bar 380 bar 380 bar
Stroke 150mm
Forward Speed 27.22 mm/sec 21.69 mm/sec 20.17 mm/sec 16.21 mm/sec
Pressing Speed 6.94 mm/sec 6.53 mm/sec 5.93 mm/sec 4.77 mm/sec
Voltage 380-440 V
